| Dalies numeris | AA104XD02 |
| Prekės ženklas | Mitsubishi |
| Dydis | 10.4 |
| Taikymas | IA |
| Rezoliucija | 1024×768 |
| Sudėtis | LCM |
| Ryškumas | 600 |
| CR | 700:1 |
| Spalvos | 262K/16.7M |
| Foninis apšvietimas | WLED |
| Sąsaja | LVDS |
| skydelio prekės ženklas | Mitsubishi |
| skydo modelis | AA104XD02 1 Compatible model |
| skydo tipas | a-Si TFT-LCD , LCM |
| skydelio dydis | 10.4 inch |
| rezoliucija | 1024(RGB)×768 , XGA |
| rodymo rėžimas | TN, Normally White, Transmissive |
| aktyvioje srityje | 210.4×157.8 mm |
| kontūras | 230×180.2×11 mm |
| paviršius | Antiglare, Hard coating (3H) |
| ryškumas | 600 cd/m² (Typ.) |
| Kontrasto santykis | 700:1 (Typ.) |
| ekrano spalvos | 262K/16.7M (6-bit / 6-bit + Hi-FRC), CIE193140% |
| atsakymo laikas | 4/12 (Typ.)(Tr/Td) |
| žiūrėjimo kampas | 80/80/65/65 (Typ.)(CR≥10)(L/R/U/D) |
| dažnis | 60Hz |
| lempos tipas | 2 stringsWLEDWithout Driver |
| signalo sąsaja | LVDS (1 ch, 6/8-bit), 20 pins |
| įėjimo įtampa | 3.3V (Typ.) |
| taikymas | IA |
