| Dalies numeris | AA170EC01 |
| Prekės ženklas | Mitsubishi |
| Dydis | 17.0 |
| Taikymas | IA |
| Rezoliucija | 1280×1024 |
| Sudėtis | LCM |
| Ryškumas | 600 |
| CR | 800:1 |
| Spalvos | 262K/16.7M |
| Foninis apšvietimas | WLED |
| Sąsaja | LVDS |
| skydelio prekės ženklas | Mitsubishi |
| skydo modelis | AA170EC01 |
| skydo tipas | a-Si TFT-LCD , LCM |
| skydelio dydis | 17.0 inch |
| rezoliucija | 1280(RGB)×1024 , SXGA |
| rodymo rėžimas | TN, Normally White, Transmissive |
| aktyvioje srityje | 337.92×270.336 mm |
| kontūras | 358.5×296.5×17.4 mm |
| paviršius | Antiglare, Hard coating (3H) |
| ryškumas | 600 cd/m² (Typ.) |
| Kontrasto santykis | 800:1 (Typ.) |
| ekrano spalvos | 262K/16.7M (6-bit / 8-bit), CIE193172% |
| atsakymo laikas | 6/19 (Typ.)(Tr/Td) |
| žiūrėjimo kampas | 80/80/60/80 (Typ.)(CR≥10)(L/R/U/D) |
| dažnis | 60Hz |
| lempos tipas | 4 stringsWLEDWithout Driver |
| signalo sąsaja | LVDS (2 ch, 6/8-bit), 30 pins |
| įėjimo įtampa | 3.3/5.0V (Typ.)(VCC) |
| taikymas | IA |
