| Dalies numeris | B101XAN02.0 |
| Prekės ženklas | AUO |
| Dydis | 10.1 |
| Taikymas | PAD |
| Rezoliucija | 1366×768 |
| Sudėtis | LCM |
| Ryškumas | 250 |
| CR | 800:1 |
| Spalvos | 16.7M |
| Foninis apšvietimas | WLED |
| Sąsaja | MIPI |
| skydelio prekės ženklas | AUO |
| skydo modelis | B101XAN02.0 |
| skydo tipas | a-Si TFT-LCD , LCM |
| skydelio dydis | 10.1 inch |
| rezoliucija | 1366(RGB)×768 , WXGA |
| rodymo rėžimas | AHVA, Normally Black, Transmissive |
| aktyvioje srityje | 222.341×125.568 mm |
| kontūras | 235.01×138.95×4.7 mm |
| paviršius | Glare (Haze 0%), Hard coating (3H) |
| ryškumas | 250 cd/m² (Typ.) |
| Kontrasto santykis | 800:1 (Typ.) |
| ekrano spalvos | 16.7M (6-bit + Hi-FRC), CIE193150% |
| atsakymo laikas | 15/10 (Typ.)(Tr/Td) |
| žiūrėjimo kampas | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| dažnis | 60Hz |
| lempos tipas | 4 stringsWLEDWithout Driver |
| signalo sąsaja | MIPI (4 data lanes), 39 pins |
| įėjimo įtampa | 3.3V (Typ.) |
| taikymas | PAD |
