| Dalies numeris | BA070WS1-400 |
| Prekės ženklas | BOE |
| Dydis | 7.0 |
| Taikymas | MP4 |
| Rezoliucija | 1024×600 |
| Sudėtis | LCM |
| Ryškumas | 350 |
| CR | 700:1 |
| Spalvos | 262K/16.7M |
| Foninis apšvietimas | WLED |
| Sąsaja | LVDS |
| skydelio prekės ženklas | BOE |
| skydo modelis | BA070WS1-400 |
| skydo tipas | a-Si TFT-LCD , LCM |
| skydelio dydis | 7.0 inch |
| rezoliucija | 1024(RGB)×600 , WSVGA |
| rodymo rėžimas | TN, Normally White, Transmissive |
| aktyvioje srityje | 153.6×90 mm |
| kontūras | 167.25×104.65×3 mm |
| paviršius | Clear, Hard coating |
| ryškumas | 350 cd/m² (Typ.) |
| Kontrasto santykis | 700:1 (Typ.) |
| ekrano spalvos | 262K/16.7M (6-bit / 6-bit + Hi-FRC), CIE193150% |
| atsakymo laikas | 20 (Typ.)(Tr+Td) |
| žiūrėjimo kampas | 70/70/70/60 (Typ.)(CR≥10)(L/R/U/D) |
| dažnis | 60Hz |
| lempos tipas | 3S6PWLEDWithout Driver |
| signalo sąsaja | LVDS (1 ch, 6/8-bit), 39 pins |
| įėjimo įtampa | 3.3V (Typ.) |
| taikymas | MP4 |
