| Dalies numeris | HE070IA-04R |
| Prekės ženklas | Innolux |
| Dydis | 7.0 |
| Taikymas | PAD |
| Rezoliucija | 800×1280 |
| Sudėtis | CELL |
| Ryškumas | 0 |
| CR | 800:1 |
| Spalvos | 16.7M |
| Foninis apšvietimas | No B/L |
| Sąsaja | LVDS |
| skydelio prekės ženklas | CHIMEI INNOLUX |
| skydo modelis | HE070IA-04R |
| skydo tipas | a-Si TFT-LCD , CELL |
| skydelio dydis | 7.0 inch |
| rezoliucija | 800(RGB)×1280 , WXGA |
| rodymo rėžimas | IPS, Normally Black, Transmissive |
| aktyvioje srityje | 94.2×150.72 mm |
| kontūras | 101.5×159.52×1.27 mm |
| paviršius | Hard coating |
| stiklo gylis | 0.50+0.50 mm |
| pralaidumas | 3.6% (Typ.)(with Polarizer) |
| Kontrasto santykis | 800:1 (Typ.) |
| ekrano spalvos | 16.7M (8-bit), CIE193160% |
| atsakymo laikas | 50 (Typ.)(Tr+Td) |
| žiūrėjimo kampas | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| dažnis | 60Hz |
| signalo sąsaja | LVDS (1 ch, 8-bit), 40 pins |
| įėjimo įtampa | 3.3/8.8/-7.0/22V (Typ.)(VDD/AVDD/VGH/VGL) |
| taikymas | PAD |
