| Dalies numeris | HT170EX1-101 |
| Prekės ženklas | BOE |
| Dydis | 17.0 |
| Taikymas | DMPC |
| Rezoliucija | 1280×1024 |
| Sudėtis | LCM |
| Ryškumas | 300 |
| CR | 700:1 |
| Spalvos | 16.2M |
| Foninis apšvietimas | CCFL |
| Sąsaja | LVDS |
| skydelio prekės ženklas | BOE |
| skydo modelis | HT170EX1-101 3 Compatible model |
| skydo tipas | a-Si TFT-LCD , LCM |
| skydelio dydis | 17.0 inch |
| rezoliucija | 1280(RGB)×1024 , SXGA |
| rodymo rėžimas | TN, Normally White, Transmissive |
| aktyvioje srityje | 337.92×270.336 mm |
| kontūras | 354.9×290.3×13.5 mm |
| paviršius | Antiglare (Haze 25%), Hard coating (3H) |
| ryškumas | 300 cd/m² (Typ.) |
| Kontrasto santykis | 700:1 (Typ.) |
| ekrano spalvos | 16.2M (6-bit + FRC) |
| atsakymo laikas | 2/6 (Typ.)(Tr/Td) |
| žiūrėjimo kampas | 75/75/75/60 (Typ.)(CR≥10)(L/R/U/D) |
| dažnis | 60Hz |
| lempos tipas | 4 pcsCCFLWithout Driver |
| signalo sąsaja | LVDS (2 ch, 8-bit), 30 pins |
| įėjimo įtampa | 5.0V (Typ.) |
| taikymas | DMPC |
| B170PW03 V3 | AUO | 17.0 | 1440×900 |
| HT170E01-300 | BOE | 17.0 | 1280×1024 |
| HT170E02-100 | BOE | 17.0 | 1280×1024 |
| HT170EX1-101 | BOE | 17.0 | 1280×1024 |
| HT170EX1-300 | BOE | 17.0 | 1280×1024 |
| LM170E03-TLB1 | LG Display | 17.0 | 1280×1024 |
| LTN170CT08-001 | Samsung | 17.0 | 1920×1200 |
| MT170EN01 V.1 | Innolux | 17.0 | 1280×1024 |
| N170C3-L01 | Innolux | 17.0 | 1440×900 |
| TD170WGCB2 | TPO | 17.0 | 1280×1024 |
| HR215WU1-120 | BOE | 21.5 | 1920×1080 |
| HT190WG3-100 | BOE | 19.0 | 1440×900 |
| LM150X08-A4KD | LG Display | 15.0 | 1024×768 |
| LM150X08-TLB1 | LG Display | 15.0 | 1024×768 |
| LM190E09-TLK1 | LG Display | 19.0 | 1280×1024 |
| LM270WF7-SSA1 | LG Display | 27.0 | 1920×1080 |
| M190A1-L02 | Innolux | 19.0 | 1440×900 |
| M190PW01 V8 | AUO | 19.0 | 1440×900 |
| MT190AW02 V.0 | Innolux | 19.0 | 1440×900 |
| NL128102BC29-01C | NLT | 19.0 | 1280×1024 |
