| Dalies numeris | HT260WX2-101 |
| Prekės ženklas | BOE |
| Dydis | 26.0 |
| Taikymas | LCTV |
| Rezoliucija | 1366×768 |
| Sudėtis | CELL |
| Ryškumas | 0 |
| CR | 800:1 |
| Spalvos | 16.7M |
| Foninis apšvietimas | No B/L |
| Sąsaja | LVDS |
| skydelio prekės ženklas | BOE |
| skydo modelis | HT260WX2-101 |
| skydo tipas | a-Si TFT-LCD , CELL |
| skydelio dydis | 26.0 inch |
| rezoliucija | 1366(RGB)×768 , WXGA |
| rodymo rėžimas | TN, Normally White, Transmissive |
| aktyvioje srityje | 575.769×323.712 mm |
| kontūras | 592×339.8 mm |
| paviršius | Antiglare (Haze 25%), Hard coating (3H) |
| stiklo gylis | 0.70+0.70 mm |
| pralaidumas | 7.05% (Typ.)(with Polarizer) |
| Kontrasto santykis | 800:1 (Typ.) |
| ekrano spalvos | 16.7M (6-bit + Hi-FRC), CIE193172% |
| atsakymo laikas | 5 (Typ.)(G to G) |
| žiūrėjimo kampas | 80/80/80/70 (Typ.)(CR≥10)(L/R/U/D) |
| dažnis | 60Hz |
| signalo sąsaja | LVDS (1 ch, 8-bit), 30 pins |
| įėjimo įtampa | 12.0V (Typ.) |
| taikymas | LCTV |
