| Dalies numeris | LTN070NL01 |
| Prekės ženklas | Samsung |
| Dydis | 7.0 |
| Taikymas | PAD |
| Rezoliucija | 1024×600 |
| Sudėtis | LCM |
| Ryškumas | 400 |
| CR | 800:1 |
| Spalvos | 16.2M |
| Foninis apšvietimas | WLED |
| Sąsaja | LVDS |
| skydelio prekės ženklas | SAMSUNG |
| skydo modelis | LTN070NL01 |
| skydo tipas | a-Si TFT-LCD , LCM |
| skydelio dydis | 7.0 inch |
| rezoliucija | 1024(RGB)×600 , WSVGA |
| rodymo rėžimas | PLS, Normally Black, Transmissive |
| aktyvioje srityje | 153.6×90 mm |
| kontūras | 164.05×100.86 mm |
| paviršius | Glare (Haze 0%), Hard coating (3H) |
| ryškumas | 400 cd/m² (Typ.) |
| Kontrasto santykis | 800:1 (Typ.) |
| ekrano spalvos | 16.2M (6-bit + FRC), CIE193150% |
| atsakymo laikas | 30 (Typ.)(Tr+Td) |
| žiūrėjimo kampas | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| dažnis | 60Hz |
| lempos tipas | 6S4PWLEDEmbedded (LED Driver) |
| signalo sąsaja | LVDS (1 ch, 8-bit), 31 pins |
| įėjimo įtampa | 3.7V (Typ.) |
| taikymas | PAD |
