| Dalies numeris | LTP280QV-E01 |
| Prekės ženklas | Samsung |
| Dydis | 2.8 |
| Taikymas | MPH |
| Rezoliucija | 240×320 |
| Sudėtis | LCM |
| Ryškumas | 110 |
| CR | 150:1 |
| Spalvos | 262K |
| Foninis apšvietimas | WLED |
| Sąsaja | TTL |
| skydelio prekės ženklas | SAMSUNG |
| skydo modelis | LTP280QV-E01 |
| skydo tipas | a-Si TFT-LCD , LCM |
| skydelio dydis | 2.8 inch |
| rezoliucija | 240(RGB)×320 , QVGA |
| rodymo rėžimas | TN, Normally White, Transflective |
| aktyvioje srityje | 43.2×57.6 mm |
| kontūras | 52.9×71.7×4.75 mm |
| paviršius | Hard coating (3H) |
| ryškumas | 110 cd/m² (Typ.) |
| Kontrasto santykis | 150:1 (Typ.)(Transmissive)6:1 (Typ.)(Reflective) |
| ekrano spalvos | 262K (6-bit), CIE193130% |
| atsakymo laikas | 35 (Typ.)(Tr+Td) |
| žiūrėjimo kampas | 50/40/40/50 (Typ.)(CR≥10)(L/R/U/D) |
| lempos tipas | 6S1PWLEDWithout Driver |
| signalo sąsaja | Parallel RGB (1 ch, 6-bit), 61 pins |
| įėjimo įtampa | 3.3/5.0/15/-10V (Typ.)(DVDD/AVDD/VON/VOFF) |
| taikymas | MPH |
