| Dalies numeris | TM057KDH05 |
| Prekės ženklas | Tianma |
| Dydis | 5.7 |
| Taikymas | IA |
| Rezoliucija | 320×240 |
| Sudėtis | LCM |
| Ryškumas | |
| CR | 500:1 |
| Spalvos | 262K |
| Foninis apšvietimas | WLED |
| Sąsaja | TTL |
| skydelio prekės ženklas | TIANMA |
| skydo modelis | TM057KDH05 |
| skydo tipas | a-Si TFT-LCD , LCM |
| skydelio dydis | 5.7 inch |
| rezoliucija | 320(RGB)×240 , QVGA |
| rodymo rėžimas | TN, Normally White, Transmissive |
| aktyvioje srityje | 115.2×86.4 mm |
| paviršius | Antiglare, Hard coating (3H) |
| ryškumas | |
| Kontrasto santykis | 500:1 (Typ.) |
| ekrano spalvos | 262K (6-bit), CIE193150% |
| atsakymo laikas | 20 (Typ.)(Tr+Td) |
| žiūrėjimo kampas | 70/70/60/70 (Typ.)(CR≥10)(L/R/U/D) |
| dažnis | 60Hz |
| lempos tipas | WLED |
| signalo sąsaja | Parallel RGB (1 ch, 6-bit), 40 pins |
| įėjimo įtampa | 3.3V (Typ.) |
| taikymas | IA |
