| Dalies numeris | TM070RDH10 |
| Prekės ženklas | Tianma |
| Dydis | 7.0 |
| Taikymas | DPF |
| Rezoliucija | 800×480 |
| Sudėtis | LCM |
| Ryškumas | 450 |
| CR | 500:1 |
| Spalvos | 262K/16.7M |
| Foninis apšvietimas | WLED |
| Sąsaja | TTL |
| skydelio prekės ženklas | TIANMA |
| skydo modelis | TM070RDH10 2 Compatible model |
| skydo tipas | a-Si TFT-LCD , LCM |
| skydelio dydis | 7.0 inch |
| rezoliucija | 800(RGB)×480 , WVGA |
| rodymo rėžimas | TN, Normally White, Transmissive |
| aktyvioje srityje | 154.08×85.92 mm |
| kontūras | 164.9×100×6 mm |
| paviršius | Antiglare |
| ryškumas | 450 cd/m² (Typ.) |
| Kontrasto santykis | 500:1 (Typ.) |
| ekrano spalvos | 262K/16.7M (6-bit / 6-bit + Dithering), CIE193150% |
| atsakymo laikas | 25 (Typ.)(Tr+Td) |
| žiūrėjimo kampas | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| dažnis | 60Hz |
| lempos tipas | 3S8PWLEDWithout Driver |
| signalo sąsaja | Parallel RGB (1 ch, 8-bit), 50 pins |
| įėjimo įtampa | 3.3/12.5/22.0/-7.0V (Typ.)(VCC/AVDD/VGH/VGL) |
| taikymas | DPF |
